| Model No. | Power(Max.w) | lout(mA) | Vout(V-DC) | Type.Eff. | Ripple Current | DIP Switch(3 level Current) | DIM.(L*W*Hmm) |
| PSR25WxxxT2 | 25W | 120-350 | 71-208 | 90% | <5% | 50-100% | 188*30*22 |
| PSR40WxxxT2 | 40W | 200-540 | 74-200 | 92% | <5% | 50-100% | 188*30*22 |
| PSR50WxxxT2 | 50W | 250-500 | 100-200 | 93% | <5% | 50-100% | 228*30*22 |
| PSR60WxxxT2 | 60W | 290-600 | 100-207 | 93% | <5% | 50-100% | 228*30*22 |
| PSR75WxxxT2 | 75W | 350-600 | 125-214 | 93% | <5% | 50-100% | 228*30*22 |
| PSN25WxxxT2 | 25W | 120-350 | 71-208 | 90% | <5% | 100% | 188*30*22 |
| PSN40WxxxT2 | 40W | 200-540 | 74-200 | 92% | <5% | 100% | 188*30*22 |
| PSN50WxxxT2 | 50W | 250-500 | 100-200 | 93% | <5% | 100% | 228*30*22 |
| PSN60WxxxT2 | 60W | 290-600 | 100-207 | 93% | <5% | 100% | 228*30*22 |
| PSN75WxxxT2 | 75W | 350-600 | 125-214 | 93% | <5% | 100% | 228*30*22 |
